Introduction to Goniophotometry and Market Considerations

Goniophotometers are precision optical instruments designed to measure the spatial distribution of luminous intensity, chromaticity, and other photometric properties of light sources. These devices play a critical role in industries requiring compliance with international standards, including LED manufacturing, display testing, and urban lighting design. Pricing for goniophotometers varies significantly based on measurement accuracy, automation capabilities, and compliance with regulatory frameworks such as IEC, CIE, and ANSI standards.

This guide examines the LISUN LSG-6000 goniophotometer, a high-precision instrument engineered for advanced photometric analysis. We explore its technical specifications, testing methodologies, and competitive advantages in comparison to alternative solutions.

Technical Specifications of the LISUN LSG-6000 Goniophotometer

The LSG-6000 is a fully automated goniophotometer designed for comprehensive luminous intensity distribution (LID) measurements. Key specifications include:

The system integrates a high-sensitivity spectrometer and a robotic positioning mechanism, ensuring repeatable measurements for R&D and quality assurance applications.

Testing Principles and Methodologies

Goniophotometric analysis involves measuring luminous flux distribution across multiple spatial angles. The LSG-6000 employs a moving detector method, where a photometer or spectrometer captures light intensity while the sample rotates along vertical (C-axis) and horizontal (γ-axis) planes.

Key Measurement Processes:

1. Absolute Luminous Flux Measurement – Quantifies total emitted light (in lumens) via an integrating sphere or direct goniometric analysis.
2. Beam Angle and Field Angle Determination – Calculates angular spread where luminous intensity drops to 50% (beam angle) and 10% (field angle) of peak candela values.
3. Color Uniformity Analysis – Evaluates chromaticity shifts (Δu’v’) across different viewing angles, critical for display and medical lighting applications.
4. Glare Evaluation – Assesses discomfort glare metrics (UGR, TI) for architectural and urban lighting compliance.

The system’s software automates data acquisition, applying corrections for ambient reflections and detector linearity per CIE 121-1996 guidelines.

Industry Applications and Compliance Standards

1. LED & OLED Manufacturing

The LSG-6000 verifies spatial color consistency and luminous efficacy of LED modules, ensuring adherence to ANSI C78.377 and IEC 62612. Manufacturers utilize its high angular resolution to detect binning deviations in automotive and display backlighting applications.

2. Display Equipment Testing

For LCD and OLED displays, the system measures viewing angle performance per IEC 62341-6-3, quantifying luminance drop and color shift at oblique angles.

3. Photovoltaic Industry

Solar simulators and concentrator optics require precise angular light distribution analysis. The LSG-6000 validates collimation efficiency per ASTM E927 standards.

4. Urban Lighting Design

Municipalities and lighting designers rely on the system to optimize streetlight uniformity (EN 13201) and minimize light pollution (IDA/IES Model Lighting Ordinance).

5. Medical Lighting Equipment

Surgical and diagnostic lighting must meet ISO 15004-2 for shadow reduction and color rendering. The LSG-6000 provides traceable data for FDA and CE certifications.

Competitive Advantages of the LSG-6000

1. Robotic Automation – Dual-axis robotic movement reduces manual intervention, improving repeatability (±0.05° positioning accuracy).
2. Multi-Standard Compliance – Supports LM-79-19, CIE S025, and DIN 5032-7, eliminating the need for secondary validation systems.
3. High-Speed Data Acquisition – Real-time spectrometer integration enables rapid testing of pulsed LEDs (PWM frequencies up to 20kHz).
4. Modular Design – Optional environmental chambers allow thermal testing (-30°C to +80°C) for automotive and aerospace applications.

Comparative benchmarks indicate a 15–20% reduction in measurement uncertainty versus traditional goniophotometers, attributed to its calibrated reference detector and stray-light suppression.

Pricing Considerations and ROI Analysis

Goniophotometer pricing varies based on:

• Measurement Accuracy (Class A vs. Class L)
• Automation Level (manual vs. robotic)
• Regulatory Compliance (full IEC/CIE support vs. basic models)

The LSG-6000 occupies a premium segment (≈$50,000–$80,000), justified by its compliance with LM-82 (LED thermal testing) and IES TM-30-18 (color fidelity metrics). For high-throughput labs, the system’s <5-minute per test cycle reduces operational costs by 30% over semi-automated alternatives.

FAQ Section

Q1: What is the minimum sample size required for LSG-6000 testing?
The system accommodates light sources from 5mm to 2m in diameter, with adjustable mounting fixtures for irregular shapes.

Q2: How does the LSG-6000 handle ambient light interference?
A blackout enclosure and synchronous detection algorithms minimize ambient noise, per CIE 198:2011 recommendations.

Q3: Can the system measure flicker and temporal light artifacts?
Yes, with an optional high-speed photodiode module (up to 100kHz sampling rate) for IEEE 1789 compliance.

Q4: What software interfaces are supported?
The system exports IES/LDT files for Dialux, Relux, and AGi32, with API integration for LabVIEW and Python.

Q5: Is the LSG-6000 suitable for UV/IR light source testing?
Extended-range spectrometers (250nm–1100nm) are available for UV curing and IR sensor validation.

This guide underscores the LSG-6000 as a benchmark for precision photometry, addressing the stringent demands of modern lighting and optical industries.
