Surge Monitor

Product No: SG-M10

Leave a Message

Your email address will not be published. Required fields are marked *

Specifications

SG-M10 Surge Monitor built-in surge voltage and current probe. After connecting with LISUN OSP1102 Digital Oscilloscope, it can real-time monitor Surge Generator SG61000-5SA/SB and SG61000-5NA/NB surge 1.2/50us and 8/20us output waveform, real-time display of surge peak voltage and peak current, and real-time monitor surge breakdown voltage and breakdown current of EUT. Thus make the surge test process more direct and facilitate fault diagnosis.

Optimized for the surge waveforms specified in GB/T 17626.5 and IEC 61000-4-5. The test results with high accuracy and good stability.

Maximum peak voltage	±10kV ±10％
Maximum peak current	±5kA ±10％
Voltage attenuation ratio	1000:1
Current attenuation ratio	1000:1
Accuracy	>5％
Surge peak voltage and peak current display	LCD synchronous display
Surge voltage and current monitoring output	BNC coaxial terminal, ≥1MΩ
Power Supply	AC220±10％ 50/60Hz （110V customizable）

Download

SG-M10 Surge Monitor Brochure
